Product Description

Today’s modern homes are being built with the utmost attention to energy savings. In urban areas, smaller and more efficient furnaces are in demand because with oversized higher efficiency furnaces the efficiency savings are ultimately being wasted and the furnace life shortened. With these trends at an all time high, there is a need for lower BTU furnaces. Napoleon® meets this challenge with one of the smallest furnaces and the lowest input of 30,000 BTU’s in the industry. Napoleon 9200 Series Gas Furnace start at the industry’s lowest input of 30,000 BTU’s and range up to 120,000 BTU’s, with AFUE’s (Annual Fuel Utilization Efficiency) up to 94%. These furnaces, with their superior design and engineering, provide reliable, safe and efficient heat for your home. With 10 models to choose from, there is one perfectly suited for your home.

Corrosion Resistant Heavy Gauge Aluminized-Steel Tubular Triple-Pass Heat Exchanger

• Controlled wrinkle-bend design of heat exchanger creates tubes with consistent thickness and no weak areas
• Highly-efficient triple pass tubular design has a large surface area to maximize heat transfer
• Each row of tubes is offset to increase turbulence in the airflow and maximize heat transfer

Stainless Steel Heat Recovery Coil

• Extracts the remaining heat from the flue gases once they exit the triple-pass heat exchanger
• Increases efficiency by evenly distributing the remaining heat to the coil’s large fins
• The Heat Exchanger is backed by our President’s Limited Lifetime and Limited Replacement Guarantee* for your peace of mind

Aluminized Multi Port in Shot Burners

• Corrosion resistant burners with Napoleon 9200 Series Gas Furnace
• Perfectly shapes the flame cone for maximum flame efficiency

Self Diagnostic Integrated Furnace Control (IFC)

• Contains LED service indicator lights to ensure quick and accurate service calls
• Constantly monitors all safety devices on Napoleon 9200 Series Gas Furnace
• Interfaces with additional home comfort products using simple plug-in connections
• Mounted between the blower rails for easy accessibility

Key features

• One of the smallest 92.1% AFUE furnaces on the market
• Factory-fired and tested for trouble-free start-ups
• Multi-position (upflow, horizontal right and left)
• Multiple intake/venting, gas pipe and electrical connection options
• Certified to 4500 feet in Canada with no modification
• Clear condensate collector to view furnace performance

10 years parts limited warranty and 20 years heat exchanger limited warranty.
